AHN myLab Hot Plate Stirrer

판매가격 1,246,400 원
카탈로그 NO. 7-305-00-0
제조사/원산지 ahn / Germany
제품사양 정보

카탈로그 다운로드

AHN-Benchtop-Catalogue.pdf

Order Information

AHN myLab® Hot Plate Stirrer

Catalog No. Description 브랜드 단위 소비자가 추가
Catalog No.7-305-00-0 DescriptionSM-05 5-plate Hot Plate Magnetic Stirrer 1500 rpm 브랜드ahn 단위 소비자가1,246,400원
Catalog No.7-310-00-0 DescriptionM-10 10-plate Hot Plate Magnetic Stirrer 1500 rpm 브랜드ahn 단위 소비자가1,763,200원
Catalog No.7-315-00-0 DescriptionSM-15 15-plate Hot Plate Magnetic Stirrer 1500 rpm 브랜드ahn 단위 소비자가2,294,400원

선택한 항목

Catalog No. Description 소비자가
총 합계 금액 0원


AHN myLab® Hot Plate Stirrer

AHN myLab® Hot Plate Stirrer is available in 3 options, as 5-, 10- and 15-place Magnetic Stirrer Hot Plate. Regardless capacity, AHN myLab® Hot Plate Stirrer is ideal for synchronous heating and stirring of liquids in multiple bottles.
Contact us to test AHN myLab® Hot Plate Stirrer free of charge worldwide.


Technology behind AHN myLab® Hot Plate Stirrer

Equipped with a powerful Brushless DC motor, AHN multi-bottle magnetic stirrer hot plate is maintenance-free. This Hot Plate Stirrer sustains stability at the low speed and vortexes samples in a powerful way at the high speed. Microprocessor controlled, AHN myLab® Hot Plate Stirrer not only maintains its set speed even under changing load or viscosity conditions, but also saves the last run parameters.


Universality of AHN Magnetic Stirrer Hot Plate

AHN myLab® Hot Plate Stirrer offers a stainless steel platform surface with a silicone resin pad which is non-slip and corrosion resistant. The lightweight and low-profile of this magnetic stirrer hot plate takes only the very minimum of your bench space. All 3 models of AHN magnetic stirrer hot plate have variable speed ranging from 300 to 1500 rpm in steps of 10 rpm. AHN myLab® Hot Plate Stirrer heats the samples up to 120 °C. A “Hot” warning light flashes whenever the heater temperature goes above 50°C.


Homogeneous heating and work comfort with AHN myLab® Hot Plate Stirrer

AHN myLab® Hot Plate Stirrer offers you the most homogeneous temperature distribution across the whole heating plate. This magnetic stirrer hot plate has an independent digital display for speed, time and temperature. Equipped with a self-intuitive touch pad, AHN myLab® Hot Plate Stirrer makes it easy to control your stirring process. You can set the timer from 1 to 999 minutes, or process your samples continuously in the infinite mode. Programmable Pulse mode of AHN myLab® Hot Plate Stirrer improves your mixing and can be set up with time intervals of 30-99 seconds.


Work safely with AHN myLab® Hot Plate Stirrer

AHN magnetic stirrer hot plate has a closed design, enabling easy cleaning and protecting the hot plate stirrer from accidental spillage. On the top of that, AHN magnetic stirrer hot plate comes with a water proof heater with inbuilt safety cut-off and non-slip rubber feet, assuring firm grip on your bench, even at the maximum stirring speed. AHN magnetic stirrer hot plate is IP 42 compliant. You can work with AHN myLab® Hot Plate Stirrer in incubators and cold rooms, when processing temperature sensitive samples.


DescriptionCat. No.
AHN myLab® SM-05 5-plate Hot Plate Magnetic Stirrer 1500 rpm7-305-00-0
AHN myLab® SM-10 10-plate Hot Plate Magnetic Stirrer 1500 rpm7-310-00-0
AHN myLab® SM-15 15-plate Hot Plate Magnetic Stirrer 1500 rpm7-315-00-0
Delivery package
1 pc.Hot Plate Magnetic
Stirrer 1500 rpm
1 pc.Power cord
1 pc.Reference stirrer bar
1 pc.Instruction manual
1 pc.Warranty card
Specifications
Number of stirring
Positions
51015
Max. stirring quantity400 mL per position
Recommended
stir bar length
25 mm
Protection classIP 42
Dimensions (WxDxH)136 x 562 x 75 mm196 x 565 x 75 mm282 x 568 x 76 mm
Weight3.0 kg5.0 kg7.0 kg
