5mm Micro Cell Assembly (use with small sample sizes in thin wall tube)

판매가격 62,400 원
카탈로그 NO. FAMILY-1381
제조사/원산지 Wilmad-LabGlass /
제품사양 정보

카탈로그 다운로드

SP Wilmad-LabGlass NMR Consumable and Accessories.pdf
다운로드

Order Information

Catalog No. Description 브랜드 단위 소비자가 추가
Catalog No.529-A DescriptionSpherical NMR Bulb 18 ul 브랜드Wilmad 단위10/Pk 소비자가134,300원
Catalog No.529-D DescriptionStraight Capillary Tube 61 ul 브랜드Wilmad 단위10/Pk 소비자가72,700원
Catalog No.529-E Description5 mm Cylindrical Bulb Microcell Insert 110 ul 브랜드Wilmad 단위1 ea 소비자가62,400원

선택한 항목

Catalog No. Description 소비자가
총 합계 금액 0원
구매하기
장바구니
찜하기


5mm Micro Cell Assembly (use with small sample sizes in thin wall tube)

•Sample volume can be as little as 18 µL.•3 different inserts with various shapes (Spherical Bulb, Capillary Tube and Cylindrical Bulb)•Outer tube (Precision Thin Walled) must be ordered separately depending on magnetic field strength.•Not recommended for variable temperature experiments.•Use our PTFE Needles (#90630) with syringes to fill and clean sample.



529-A Specifications

  • Fits Tube:Wilmad Precision 5 mm Thin Wall (for example 528-PP-7)
  • Description:Spherical Bulb with Stem
  • Spherical Bulb Inner Volume (µL):18
  • Overall Length (inch): 1.75
  • Stem I.D. (mm):1.0
  • Stem O.D. (mm):1.5
  • Bulb Outer Radius (mm):4.14
  • Qty Per Pack:10


529-D Specifications

  • Compatible with:529-B into 5 mm thin wall tube
  • Description:Capillary Tube
  • OD (mm):1.5
  • ID (mm):1.0
  • Volume µL:61
  • Length (mm): 76
  • Qty Per Pack:10


529-E Specifications

  • Fits Tube OD (mm):5
  • Description:Cylindrical Bulb
  • Volume µL:110
  • Length (mm):12
  • Qty Per Pack:1



Application Notes

Cylindrical microcells can be customized in lengths to match your probe Note: Positioning rod should be removed prior to recording the spectrum. Technical Tip: To improve the shimming quality and signal lock, surround the microcell with reference solvent to reduce the susceptibility differences between the inner and outer compartments of the assembly. Resonance Report: For detailed explanations of the application of Coaxial Inserts and Microsampling see Resonance Report NMR-007 and NMR-008
